Vollmer CAL 200

Technical Specifications

• Manufacturer: VOLLMER Technique d’Affûtage S.A.R.L., France
• Model: CAL 200
• Year of manufacture: 2004
• Serial No.: 310
• Machine type: CNC profile sharpening machine
• Application: Cut-off and band saw blades
• Tooth feed: from the left
• Blade width: 70–270 mm
• Blade length: starting at 5.5 m
• Blade thickness: up to 2.8 mm
• Tooth pitch: 6–120 mm
• Tooth height: up to 40 mm
• Rake angle: up to 40°
• Grinding wheels: corundum and CBN
• Grinding wheel diameter: 250 mm
• Working speed: approx. 5–30 teeth/min
• Grinding method: wet grinding
• Cooling: integrated coolant system
• Design: fully enclosed
• Grinding control: CNC
• Tooth feed: CNC-controlled
• Automatic dressing: optional or depending on configuration
• Power rating: approx. 4.3 kVA / 4.8 kW
• Weight: approx. 1,025 kg

The VOLLMER CAL 200 is a CNC-controlled profile sharpening machine for cut-off and block band saw blades. The machine uses wet grinding and is designed for the precise resharpening or profile grinding of band saw blades. The CAL 200 features an automatic tooth feed and can process various tooth profiles.
